Some years ago, veteran sound designer and game audio director Zachary Quarles (DOOM, Quake, Killer Instinct, Wolfenstein & many more) wrote an excellent guide on how to do an audio design document – and this is his followup to that guide; one that may very well change your life game for the better!

Here’s Zachary Quarles, with his insights on what you need to consider when doing an audio design document today – and why it’s such an essential tool for making your game sound its best:





Several years ago, I wrote this blog post over on my webpage. It essentially broke down how important establishing an audio vision is when an audio director starts their project and what high-level topics should be addressed when writing the primary audio design document that should become your roadmap when going into pre-production and subsequently building your game. It’s a fairly long read but it’s pretty fancy. It has bullet points, people…BULLET POINTS. I am so sophisticated.

We are knee-deep in a new console cycle where games are even more complex and in need of strong direction and commitment from all disciplines

Well, quite a bit of time has passed. We are knee-deep in a new console cycle where games are even more complex and in need of strong direction and commitment from all disciplines in order to execute at the level that our customers expect. How do we prepare for that? Game production can change at a moment’s notice, which can cause chaos if you’re trying to keep a large design document up to date and relevant throughout a busy production cycle. We need to start with an incredibly strong foundation and yet we need to be nimble, be able to make adjustments very rapidly, and not feel weighed down to a massive tome.

Has this new world of game production changed my approach as an audio director?

Good question. I hadn’t really thought about it much as I’ve been in the thick of a pretty aggressive release cycle with Killer Instinct (the game is broken up by seasons and has been in an active release cadence since 2013…which is a whole different article that I should write at some point) and spinning several other unannounced projects around, but I recently received that very inquiry from Asbjoern via a Twitter direct message. This caused me to take a step back and look at the last few years both as a developer AND a publishing audio director to see if my approach has adjusted.

I present to you: Writing an Audio Design Document: Part II!

Oooohhh…a sequel!

In my original article, I mapped out tons of high-level components that make up a game’s sonic identity and items that should be discussed and planned on when starting a project, moving into pre-production, and continued throughout production. Obviously, I still believe that is incredibly important…however, as we all know, games change and people are busy. Production cycles aren’t always predictable and the needs of the project evolve over time. So too, must the audio direction of the game if you want them to be a symbiotic entity.

This article is an addendum to my original. It’s geared toward the audio director, but it ties into all disciplines. I’ll go a bit more down the rabbit hole in terms of how I personally format audio documentation and feature sets to make sure they are clearly decipherable not only to the audio team but also to the creative director, designers, artists, programmers, and producers. A big part of my job as a publishing audio director is to make sure that everyone is on the same page and has buy-in with what we are doing from an audio standpoint. That means lots of streamlining and having laser-sharp clarity on the needs of other departments.

So how do you distill your game’s audio vision down to a digestible format that people can completely understand at a glance?

No one wants to have to read a novel if they are already incredibly busy (which everyone is). So how do you distill your game’s audio vision down to a digestible format that people can completely understand at a glance?

My current approach focuses on three primary phases. Step one in this journey is establishing what we call “Audio Pillars”.


AUDIO PILLARS

Audio Pillars are high-level “filters” that distill the game’s full audio aesthetic and feature-set down to a handful of descriptors. I tend to use 3-5 of these and use somewhat flowery language to give an emotional connection to each pillar so people can relate to them at a human level and can understand what sort of feature (or set of features) would have to be implemented in order to properly have the Audio Pillar realized. Use of additional descriptive text also clues the creative team into the aesthetic that should be established and maintained. I approach this almost like writing prose as opposed to a technical document. The art, design, and programming departments utilize this same process; so all disciplines are in lock step on what the big-picture goals of the game are. They serve as your “north star” as you’re plodding through pre-production and on into production.

It usually takes a bit of iteration and interaction with the art, design, and programming departments as we figure out what the game actually “is” to get these Pillars locked down. After they are established I often print them out and hang them on my wall to make sure they are always there and I’m constantly reminded of where I need to go. This is also helpful for me because I am usually working on multiple projects at any given time, so if I can glance at them quickly I can drop into the proper headspace for that particular project very easily and realign my brain to live in that world as needed.

Here is an example of a possible Audio Pillar:


The Sound of a Worn-Down World that Evolves With You
Our small community is among the few that still remain on Earth. Our world is overrun with fantastical creatures and supernatural events that can change the surroundings that we inhabit, but, in the end, we are still fighting for our very existence with the weapons and tools that we scrounge and forge together.



On surface that’s just some descriptive text…clumsily constructed by yours truly; but if you read further into it, an aesthetic and a set of features begin to emerge. Here are a few that we can glean:

Multiplayer/Coop – Use of “community” suggests that there is a multiplayer component and that it’s not necessarily competitive. This will require local & non-local functionality and everything that comes with that (dynamic sound bank streaming, latency compensation, voice chat, etc…)

Stylized aesthetic based in reality – Use of “worn-down”, “fantastical”, and “supernatural” which takes place on Earth. So, sound design will lean towards gritty, textured, stylized, and saturated. While the sounds themselves will be hyped and larger than life, they will maintain a certain amount of realism.

Specialized content geared towards an action game – Character Foley/Interaction, Creatures, Weapons, Combat, etc…

An evolving ambient sound system – “…supernatural events that can change the surroundings that we inhabit” suggests that scripted events, enemy/player interactions, and other situations can change the world around you, which would require a system to track what world you’re in and what the world is becoming. For example, you’re in the middle of an abandoned steel mill and you come across a slobbering beast. When it screams it rips a hole into a different dimension, which pulls in a firestorm from a raging volcano that is on the other side of the portal. Which ignites the decaying building around you and causes a huge inferno.

Robust crafting system – tools and weapons that are found and constructed by the player(s) and NPCs.

“Okay, that’s great, but that seems like a pretty esoteric exercise, Quarles. What purpose does this actually serve? Wouldn’t it be more straight-forward to map everything out as discrete features and have a style-guide for the aesthetics?”

That’s a fair point, but keep in mind that this isn’t only for the audio department. This is for the rest of the team and to maintain high level filters for the project as a whole while you’re going towards the finish line.

Keep in mind that this isn’t only for the audio department

If any of you have written a huge audio design document that maps out every single feature and a full style-guide, how many people have you actually gotten to read it? This is more to establish the overall “tone” of the game that the rest of the departments can get behind without having to be mired down in the details.

Feature breakdowns and stuff like that are handled differently, which I’ll address soon…but NOT YET. There is an important step that takes place after the Audio Pillars are written. That is the “Audio Target”.



Popular on A Sound Effect right now - article continues below:



Latest releases:
  • We have created a small library to help with the ongoing need for safety videos during this strange time in our lives. From hand sanitizer’s to spray bottles, we have compiled a library to cover all forms of day to day sanitizing.

    20 %
    OFF
    Ends 1591394399
    Add to cart
  • Jump in a hot-off-the-assembly-line 2020 Porsche 911 “992” Carrera S from the comfort of your home or studio chair. This library won’t lose a cent of value when you drive it off the lot!

    Great for linear work or games – especially since it includes an easy-to-use Interior vs. Exterior mockup folded down to 2-channel files (ISO’s also included separately).

    This is our premiere foray into sound libraries here at Steamboat Sound, and we worked real hard to make it equally high-quality and easy-to-use – we hope you enjoy!

    Recordings include:

    Mockup channel order (panned, for easy editing in NLE):
    Channel 1 (left) – Exterior
    Channel 2 (right) – Interior

    Isolated tracks of all Exterior and Interior perspectives on idles, revs, engine starts & stops, various speeds, and more!

    Interior knobs, buttons, dials, seatbelts, sunroof, turn signals, buttons, windshield wipers, door open/close.

    Recorded with industry-standard equipment used on theatrical films and name-brand commercials, for your listening pleasure.

    40 %
    OFF
    Ends 1591307999
    Add to cart
  • MAGIC SOUND EFFECTS REDEFINED

    Enter the world of MAGIC – ARCANE FORCES, where supernatural entities can be heard raging with ultimate power and fury. The distinctly forceful and kinetic character of this comprehensive sound effects library and its designs is supported by countless pristine source recordings of the elements being pushed to their limits. Whether in post production or sound design for games, MAGIC – ARCANE FORCES gives you the edge on the other side.

    WHAT’S INSIDE:
    INCLUDED SOUNDS – KEYWORDS
    ACID, ARCANE, BARRIER, BREATH, BUFF, CURSED, DEBUFF, DIVINE, ELECTRIC, ENERGY, FIRE, GLASS, ICE, IMPACT, LIGHT, LIQUID, METAL, PROCESSED, PROJECTILE, RUMBLE, SEQUENCE, SUMMON, SWEETENER, SWISH, TELEPORT, TEXTURE, VOICE, WATER, WHOOSH, WIND
    20 %
    OFF
    Ends 1591999199
  • “The Shoe Collection: Soft Hardwood – Woman’s Knee-High Boot“ by Periscope Post & Audio, provides 22 high quality footsteps on soft hardwood floors with the knee-high boot.  The audio files are recorded at 24bit, 192k with mono and stereo recordings.  The Sennheiser MKH-60 was used for the mono files with a slightly more distant mic placement than the stereo files, which were recorded with the Sennheiser MKH8050 and the Sennheiser MKH-30 near the shoe.  From different walking speeds, to jogging, sprinting, jumping, hard stops, scuffs, and more!  There are several performances with each file to fit the right action you need.  That’s a whopping 620 footsteps between the mono and stereo files!

    17 %
    OFF
    Ends 1591135199
    Add to cart
  • Recording of the Pulse Jet Snowmobile. Powered by a 50 Hz Pulse ethanol/water jet engine the same used by a WW2 V-2 rocket.


    The Pulse Jet Snowmobile sound collection shares 28 clips of field recordings in 1.42 gigabytes of audio. Powered by a 50 Hz Pulse ethanol/water jet engine the same used by a WW2 V-2 rocket, this bundle presents the snowmobile racing at extreme speeds for a mix of perspectives.

    Both onboard and exterior perspectives are shared in two takes. The exterior perspectives arrange microphones at a mix of distances at the beginning, end, and middle of the racing strip. The onboard microphones were positioned onboard the body and at the jet engine to portray steady fast driving, with bonus custom mixes of the onboard and exhaust tracks.

    The sound library includes iXML, Soundminer, BWAV, and MacOS Finder embedded metadata, metadata keyword import files for 7 languages, and Pro Tools and Reaper mixing sessions.

    Add to cart


Need specific sound effects? Try a search below:


AUDIO TARGET

After all of the disciplines on the team understand what the game actually is and the Audio Pillars are in place, establishing a solid Audio Target is an important step to lay the groundwork for the aesthetic direction in a tangible way. The Audio Target can be any number of things:

A “rip-o-matic” video — This would contain clips of previously released material from multiple sources (ie: movies, television, other games, etc) that guides the overall aesthetic direction for sound design, music, voice, and everything else. This can be something that is a few seconds long to a few minutes. It doesn’t really have to make sense in terms of a narrative—unless that is a large component of your game. It’s more like a very high-level reference piece to get the creative juices flowing and to illustrate the direction of the audio vision to the other disciplines using familiar material.

A post-scored video — A video crafted by the audio team using unique content that will help define the game’s aesthetic in a very tangible and actionable way. Again, this can use clips like the rip-o-matic but would not use previously released content as your reference point. You would strip out all audio from the clips and build it yourself. This is a good way to start building up your audio library at the very beginning of a project to start creating a ton of source material that you can use moving forward.

A “beautiful corner” — A slice of gameplay that represents key systems and content. This might be in the final engine that the game uses or it might be something that the audio team can do quickly in middleware to show off a feature in a very streamlined way. Whatever the choice might be; this option should be quick and dirty to basically act as a test-bed to see how complex and worthwhile something might become. I’ve been on projects before where a small strike team of disciplines would work on a vertical slice of a very specific feature in the game for a couple of weeks. The team would work together to make sure it was being treated seriously and would be brought up to representative quality so everyone understood the scope of what it would take to bring a feature from a test to a fully realized shippable component of the game.

A combination of any of these options — The Audio Target doesn’t have to be one specific thing. It can be smaller, digestible pieces of reference that tie to a single feature/content-type or it can be a high-level piece to give an overall aesthetic direction. You will more than likely find yourself doing multiple small audio targets over the course of the game’s pre-production cycle. It’s whatever best serves the game and whatever fits in your particular workflow.

Remember: showing is better than telling. I used to spend lots of time writing up how something should sound and getting frustrated when people wouldn’t “get it”. That was a hole in my communication style. When you give tangible examples, you’ll get buy-in.

After you have established what your Audio Target(s) will be for your title, you need to actually build it. To build it, you need features. To build features, you need cross-discipline support. To get cross-discipline support, you need to map out what you need in a succinct and straightforward way. How do you do this? Well…join me in the next section, won’t you?


AUDIO FEATURES & SYSTEMS

When mapping out specific features and systems, it’s important to be as descriptive as possible. This is when you can get very technical with your designs. You want these Audio Feature documents to be as concise as humanly possible. Not only are they for the audio team to come back to as reference over the course of a project and for other disciplines to read and be able to understand very easily, they also need to be clear enough that if you add someone new to your audio team over the course of development, they can get up to speed quickly and without any roadblocks.

If you’re using third party middleware (Audiokinetic’s Wwise or Firelight Technologies’ FMOD Studio, for example), this is a great place to have the audio team breakdown exactly how to build a system or feature set without having to roll code in very deeply. You can do the brunt of the work on your own and then you can involve the programming team for specific game hooks. Now, if you’re using proprietary technology or a codebase that doesn’t have an elaborate content creator’s authoring tool, then you might need to get a bit more detailed with the workflow, tool interface mockups, and reference examples of what you’re looking to achieve.

There are a few ways of documenting these Audio Features. I used to create one master document that contained ALL of the ideas and information that I have been discussing in this article—Audio Features, Targets, reference material, etc. But, what I’ve discovered over the years is that people tend to be a bit more responsive if you provide smaller singular chunks of data that they can consume quickly. I like to make things as easy for people to process as humanly possible and if someone starts digging into the audio documents directory, they can find what they are looking for just based off of document title. So, I have started breaking Audio Features and Systems out into individual document files. They might only be a couple of pages long each, so I can have a ton of files on any given project; but if they are named and organized in a sensible manner, I’ve found that people will actually read them.

A high-level template flow that I use when writing up a Feature or a System is as follows:

Name of the feature/system.

Which project this is designed for – This is a bit of a requirement for me and for my job since I ping-pong from project to project. That might not really be a necessity for you if you are primarily focused on a single game. Just a personal preference.

Vision Statement – Emotional design description goes here. The purpose of the emotional design is to give a high level goal to the feature. For instance engine roars that create lust, bullet whizzes that make you duck, etc. Any flowery language should go here and guide asset creators in the overall direction

Technical Design – Break these up into design goal bullet points and write up technical design description sub bullets for each design goal. Go into painstaking detail and explain how you use the asset definitions. If using something like Wwise, you can roll any RTPC (Real-Time Parameter Control) needs into this section. You might only have one or two design goals for any given feature…but…there might be some pretty beefy systems that will require multiple goals. Using bullet points keeps things straightforward and easy to read. Plus, it provides a nice reference point if you need to go back over it in the future.

Event Design – Breakdown the necessary events that will be required for this feature. This includes Create, Play, Stop, and Destroy events.

References – this is a bit of an optional section but if you are working on proprietary technology, this would be a good place to have mock-up screenshots, links to similar tools, etc…

Now, how you organize this stuff and what you choose to include in your Feature documentation is obviously completely up to you. This is my process and it allows me write up descriptive Audio Features quickly, but in a robust and focused manner. It also allows for easy maintenance and re-direction if the game’s focus changes over the course of pre-pro (or even in the middle of production). The last thing you want to have to do is constantly update documentation if you are neck-deep in shipping a game.


CONCLUSION

So, I recognize the contradiction of me constantly harping on being streamlined and succinct in your writing and then I go ahead and compose a gargantuan article that drones on and on.

What can I say? I’m a complicated person.

Seriously though. Don’t consider my process to be the “be all, end all” of how to approach a project by any stretch. This is my personal method that I’ve cobbled together after years of being a developer and then making some adjustments once I became a publishing audio director. I’m always open to new ideas, learning new methodology, and trying new practices and techniques.

While my overall goal and philosophy of audio direction hasn’t changed much over the last few years, some of the details in distributing information and communication to other departments have. I try not to be quite as myopic and specialized in my documentation any more; but rather focus on the human aspect and how audio has to be an anchor for the player experience. I try to show more than tell as often as I can. Talk to me in a couple of years and I’ll probably have another ridiculously long-winded article ready to go about how my process has changed.

Again.


A big thanks to Zachary Quarles for sharing his insights on how to create an audio design document!



Please share this:






About Zachary Quarles
Zachary Quarles has worked at companies such as id Software, Raven Software, Day 1 Studios, and is currently audio director for Microsoft in the Xbox division. He has worked on franchises such as: Killer Instinct, DOOM, Quake, RAGE, Wolfenstein, Soldier of Fortune, X-Men: Legends, and Marvel Ultimate Alliance. He occasionally writes the odd blog entry at his website. He also runs the independent game company, Winter Night Games with his brother, Josh.
